Lens is welded to housing to form single rugged unit. Kit includes 153 LED light, 150-095 mounting bracket, and plug. DOT legal when mounted horizontally with up to 32 deg. tilt back.
Operates from 9-16V. Features 2-wire, hardwired design. Ground wire includes No. 10 ring terminal. Mounts on 3″ centers. B169-18 mounting gasket included in visual pack kits, or available separately. 2-piece housing sealed with epoxy eliminates weld joints. Low cost LED alternative to traditional incandescent 154 series lights.
Surface mount. Stop, turn, and tail lamp. Features 3-3/4″ diameter wrap-over lens retained by two screws, black plastic housing, and two 10″ lead wires. Mounts with two 1/4″ studs on 2″ centers. Grounds through the mounting hardware. 2-5/8″ deep, not including mounting bolts. Snap on red lens. 12V/2.1A/.59A T.
Accepts industry standard 2-prong plug. 9-16V operating range. Visual pack kits include LED light, 142-18 grommet and 162-49 plug. The 172 is functionally equivalent to the 162 series.
